The DK-V2000 terminal-reader reads information from cards and tickets, displays the data on the display and controls the turnstile
DK-V2000 Terminal-reader is an identification device designed for checking and displaying information from electronic media at access points operating under the control of BARS payment and access control systems, BARS. EXPO-2 registration, accreditation and access control systems.
DK-V2000 Terminal-reader can work as an identification device and information kiosk
DK-V2000 Terminal-reader As Identification Device
DK-V2000 fulfils the functions of an identification device – checking, displaying information from electronic media, and controlling executive devices – turnstiles, gates, doors or barriers.
DK-V2000 Terminal-reader As Information Kiosk
DK-V2000 fulfils the functions of an information kiosk – it checks and displays information from electronic media (to check the balance, for example).
DK-V2000 Design Variants
The terminal-reader is produced in two versions – it can be a device with a barcode scanner and RFID reader, or just with an RFID reader.
Areas of Application
DK-V2000 Terminal-reader is used for payment and ticketing systems of ski resorts, stadiums and sports facilities, ice arenas, for registration and access control systems of business events and industry exhibitions, for car park automation.
DK-V2000 can be mounted on the wall, directly on the turnstile or on a special stand
with seven colour indication options identifies the passage of children, VIP and other groups
A special protective visor protects the terminal from atmospheric influences
Both the case and visor can be optionally available in different colours
The graphic display can be branded to the customer's specifications
for reading different formats - RFID media, printed barcodes or QR code cards
against mechanical damage and sun glare (optional)
Power supply voltage;12 V DC
Power consumption;60 W (with heating)
Interface with top level;ethernet 10/100
Display resolution;800×480 px
Display size;155×85 mm
Input signals;8 optocouplers (input voltage 5...25 V, input resistance 3 kOhm)
Output signals;2 relays (NO/NC) up to 125 V, 2A, 2 opto relays (NO) up to 60 Vb 0.2A
RFID reading range;5...7 cm
Overall dimensions (H×W×G); 350×194×170 mm
Operating temperature range;+50°C to 0°C (without heating), +50°C to -30°C (with heating)
